Product Details:
|
Product Name: | GHT 48V 65F Moudle | Energy Storage: | 21.6wh |
---|---|---|---|
Rated Voltage: | 48.6V | Surge Voltage: | 51.3V |
Internal Resistance(AC): | ≤ 11 MOhm | Maximum Continous Current: | 100A |
Absolute Maximun Current: | 900A | 25℃ Leakage Current: | 3.5mA |
High Voltage Insulation Test: | 2500VDC | Safety Test: | QC/T741 GB/T31484 GB/T31485 CE |
Operating Temperature Range: | Minus 40 To Plus 65 ℃ | Cycle Life: | ≥500,000 |
Protection Class: | IP65 | Product Weight: | 9.6kg |
Product Size ±5mm: | 416*196*112mm |
Scope of Main Application
• Pitching control system of Wind Turbine Generator
• Solar energy conversion system
• Hybrid drive trains
• Mass transportation braking energy recovery system
• UPS/DVC/HEV
• Heavy duty machinery
• Locomotive engine startup system
• CVG robots to trsport goods inside workshop
Supporting Quick Charging
It takes about 10 minutes to full charge
Super Capacitors Module
• Fast charge
• Low temperature performance
• Long cycle life
• High power density
• Simple charging and discharging circuit
