Product Details:
|
| Features: | Ultraportable | Type: | Li-Ion,LiFePo4,lifepo4/lithium Battery/li-ion Battery |
|---|---|---|---|
| Size: | Customized, 482*410*89mm/482*400*177mm/482*430*222mm/482*500*280mm | Cycle Life: | >6000Cycles |
| Application: | Solar System/RV/yacht/golf Carts Storage And Car/UPS | Nominal Capacity: | 2.4Kwh/5.12Kwh/10.24Kwh/12.80Kwh |
| Nominal Voltage: | 48V | Warranty: | 5 Years |
| Color: | Black(customize) | Weight: | 24KG/46KG/80KG/100KG |
| Battery Type: | LiFePo4 | Oem/odm: | Accepatable,Yes |
| Shape: | Square-shaped | Capacity: | 50ah/100ah/200ah/250sh,customized |
| Compact Desiged: | With Built-in BMS | Battery Capacity: | With LED Indicator |
| Trasportation: | By Sea/By Air/By Express | ||
| High Light: | Reusable Deep Cycle Lithium Battery,12V Deep Cycle Lithium Battery,Rack Mount 12V Lifepo4 Marine Battery |
||
Model | GH2400 | GH5000 | GH9600 | GH12000 |
Voltage | 48 V | 48 V | 48 V | 48 V |
Capacity | 50Ah | 100Ah | 200Ah | 250Ah |
Energy | 2.4Kwh | 5.12Kwh | 10.24Kwh | 12.80Kwh |
Operation voltage | 35.25-54.75 Vdc | 37.6-58.4Vdc | ||
Max.charging voltage | 54.75Vdc | 58.4 Vdc | ||
Max.charging and discharging current | 50A | 100A | ||
Max Power | 2400W | 5120W | 7680W | 12800W |
Life time(25°C) | 10 years | |||
Life cycles(80% DOD, 25°C) | 6000 Cycles | |||
Enclosure protection rating | IP65 | |||
Dimensions(L×W×H)mm | 482*410*89 | 482*400*177 | 482*430*222 | 482*500*280 |
Weight | 24KG | 46KG | 80KG | 100KG |
Lithium Battery Standard | UL,IEC, UN38.3, ROHS,CE | |||
The LiFePO4 battery, also called the LFP battery, is a type of rechargeable battery. It is the safest Lithium battery type currently available on the market today. It is made to be small in size and light in weight, and the cycle life can reach thousands of cycles.
